SPDD
- Low profile tactile switch
- SMD mounting
- RGB LED full illumination
- Wide button for 10mmx26mm and 12mmx26mm
- Application: pro audio, music synthesizer
- General Specifications
- Circuit/Contacts SPST (push ON)
- Switching rating 12V DC @ 50mA
- Terminal Surface Mounting Divice (SMD)
- Total travel 0.3mm ± 0.1mm
- Operating force 400gf ± 100gf
- Mechanical life 200,000 cycles min.
- Illumination RGB illuminated
- Materials
- Cap/Lens PC (Polycarbonate)
- Stem/Reflector PA (Polyamide)
- Base/Housing PA (Polyamide)
- Terminal CCL (Copper Clad Laminate) with gold plating
What makes SHANPU SPDD RGB SMD tactile switch unique?
SPDD tactile switch offers slim SMD design, full RGB LED lighting, and wide actuator options 10x26mm & 12x26mm, ideal for professional audio, automation and broadcasting systems.
Contact configuration & PCB layout for ZLS70 through hole lead tactile switch.
SHANPU's SPDD tact switch is a mechanical contact, illuminated switch with RGB LED, please follow the contact circuit and configuration below.
Video
Download
Sample Order
- Module
- Part No
- Description
-
- SPDDC9AAT
-
- Illumination tactile switch
- 10*26 convex
- Transparent cap
- RGB LED
-
TWD 145
- +
-
- SPDDC9BAT
-
- Illumination tactile switch
- 12*26 convex
- Transparent cap
- RGB LED
-
TWD 145
- +
*After placing the order, a specialist will contact you to inform you of the shipping date, please pay attention to your mailbox.
*EU customers please provide EORI number.
*The color is subject to the actual product.
*Sample orders are for evaluation, please contact sales representative for larger quantities.
*All products comply with RoHs and REACH.
*Obtained ISO 9001 certification in 2007.
*Obtained ISO 14001 certification in 2023.
