SLD Waterproof Rotary Encoder Push Button Switch
- Cut diameter Ø25.0mm
- IP65 protection
- White light illumination
- Tactile feedback switch
- Custom paint marking option
- Application: smart home control, coffee machine, 3C product
- General Specifications
- Circuit/Contacts Rotary encoder and SPST-NO
- Switching rating 5V
- Terminal Connector
- Total travel 0.3mm ± 0.15mm
- Operating force 800 ± 300gf
- Mechanical life Rotary encoder: C.W. 100,000 & C.C.W. 100,000 cycles; Switch: 100,000 cycles
- Front protection IP65
- Illumination White LED backlight
- Materials
- Cap/Lens Lens: Polycarbonate (PC)
- Base/Housing Base: Polycarbonate (PC), Knob: Polyamide (PA) / Aluminum
Why is IP65 important in the SLD rotary encoder switch?
The IP65-rated front panel of the SHANPU SLD switch offers strong dust and water resistance, ensuring durability and safe use in industrial environments, robotics, and smart control applications.
Contact configuration and panel cutting for SLD waterproof rotary encoder push button switch.
The SHANPU SLD switch integrates rotary and push button functions, LED display, and IP65 durability, making it perfect for user-friendly, stylish and reliable control in coffee machines.
Sample Order
- Module
- Part No
- Description
-
- SLD-PL
-
- Waterproof rotary encoder push button switch
- Panel cutting dia. 25.0mm
- Plastic silver type P knob
- 3-digit 8-character display
- White LED illuminate
-
TWD 860
- +
-
- SLD-P5
-
- Waterproof rotary encoder push button switch
- Panel cutting dia. 25.0mm
- Plastic black type P knob
- 3-digit 8-character display
- White LED illuminate
-
TWD 860
- +
-
- SLD-10
-
- Waterproof rotary encoder push button switch
- Panel cutting dia. 25.0mm
- Aluminum silver type 1 knob
- 3-digit 8-character display
- White LED illuminate
-
TWD 1,530
- +
-
- SLD-15
-
- Waterproof rotary encoder push button switch
- Panel cutting dia. 25.0mm
- Aluminum black type 1 knob
- 3-digit 8-character display
- White LED illuminate
-
TWD 1,770
- +
-
- SLD-2L
-
- Waterproof rotary encoder push button switch
- Panel cutting dia. 25.0mm
- Plastic silver type 2 knob
- 3-digit 8-character display
- White LED illuminate
-
TWD 860
- +
-
- SLD-25
-
- Waterproof rotary encoder push button switch
- Panel cutting dia. 25.0mm
- Plastic black type 2 knob
- 3-digit 8-character display
- White LED illuminate
-
TWD 860
- +
*After placing the order, a specialist will contact you to inform you of the shipping date, please pay attention to your mailbox.
*EU customers please provide EORI number.
*The color is subject to the actual product.
*Sample orders are for evaluation, please contact sales representative for larger quantities.
*All products comply with RoHs and REACH.
*Obtained ISO 9001 certification in 2007.
*Obtained ISO 14001 certification in 2023.
