Product-SLB3 Rotary encoder with CAN BUS LCD Switches-SHANPU

0 0 0

SLB3 Photo Interrupter Sensor Display Encoder Switch

Optical Incremental Rotary Encoder for reliable signal detection.
Encoder with push button + waterproof push button switch.
CAN BUS ISO 11898 communication for system compatibility.
Applications: Smart meters, EV charging stations, robotics, medical equipment, automated systems.

General Specifications
Circuit/Contacts rotary encoder and SPST-NO
Terminal cable
Operating force Switch: 800gf±300gf; Encoder: 1.5Kgf-cm(Max.)
Mechanical life Switch: 100,000 cycles min.
Front protection IP65
Illumination TFT LCD

Materials
Cap/Lens PA or PC or Aluminum alloy
Base/Housing PC
Terminal cable

Dimension- Available in a variety of sizes and designs for diverse needs.

waterproof push button switch, Taiwan rotary switch
• Optical Incremental Rotary Encoder for precision and smart applications.
• Interface: CAN BUS ISO 11898

Pin function & Panel cutting

Installation notes & Option part
