SF25BA Rotary Encoder Push Button Switch
- 25.0 mm panel cut-out diameter
- RGB LED light
- Tactile feedback function
- Personalized marking service supported
- Application: instruments and electronic devices
- General Specifications
- Circuit/Contacts Rotation + SPST Momentary (push)
- Switching rating Rotation: 0.5mA @ 5V DC; Push: 10mA @ 5V DC
- Terminal Connector
- Total travel 0.5mm ± 0.3mm
- Operating force Rotation: Max. 30 ~ 200gf.cm; Push: Max. 450gf ± 200gf
- Mechanical life Rotation: 30,000 operations; Push: 20,000 operations
- Front protection IP65
- Illumination RGB LED, Green/Red LED
- Materials
- Cap/Lens PC (Polycarbonate)
- Base/Housing PA (Polyamide)
- Terminal Brass with plating
What makes SF25BA illuminated rotary encoder switch ideal for electronic devices?
With a 25mm cutout, RGB LED illumination and rotary encoder precision, SHANPU SF25BA illuminated rotary encoder switch delivers reliable performance for appliances, audio-visual gear and automation systems.
Contact configuration and panel cutting for SF25BA illuminated rotary encoder switch.
SF25BA is ideal for smart appliances with its encoder control, RGB LED display, and secure panel installation, ensuring reliable performance in global electronics.
Video
Sample Order
- Module
- Part No
- Description
-
- SF25BAK551 + YCW014
-
- Rotary encoder push button switch
- Panel cutting dia. 25.0mm
- Black cap type 1
- Green/Red LED light
- Front panel IP65
- YCW014 wire, 8 line, 28AWG, L=30cm
-
TWD 800
- +
-
- SF25BA9552 + YCW014
-
- Rotary encoder push button switch
- Panel cutting dia. 25.0mm
- Black cap type 2
- RGB LED light
- Front panel IP65
- YCW014 wire, 8 line, 28AWG, L=30cm
-
TWD 800
- +
-
- SF25BA9553 + YCW014
-
- Rotary encoder push button switch
- Panel cutting dia. 25.0mm
- Black cap type 3
- RGB LED light
- Front panel IP65
- YCW014 wire, 8 line, 28AWG, L=30cm
-
TWD 800
- +
-
- SF25BAK554 + YCW014
-
- Rotary encoder push button switch
- Panel cutting dia. 25.0mm
- Black cap type 4
- Green/Red LED light
- Front panel IP65
- YCW014 wire, 8 line, 28AWG, L=30cm
-
TWD 800
- +
-
- SF25BA9555 + YCW014
-
- Rotary encoder push button switch
- Panel cutting dia. 25.0mm
- Black cap type 5
- RGB LED light
- Front panel IP65
- YCW014 wire, 8 line, 28AWG, L=30cm
-
TWD 800
- +
-
- SF25BA9556 + YCW014
-
- Rotary encoder push button switch
- Panel cutting dia. 25.0mm
- Black cap type 6
- RGB LED light
- Front panel IP65
- YCW014 wire, 8 line, 28AWG, L=30cm
-
TWD 800
- +
*After placing the order, a specialist will contact you to inform you of the shipping date, please pay attention to your mailbox.
*EU customers please provide EORI number.
*The color is subject to the actual product.
*Sample orders are for evaluation, please contact sales representative for larger quantities.
*All products comply with RoHs and REACH.
*Obtained ISO 9001 certification in 2007.
*Obtained ISO 14001 certification in 2023.
